Product introduction
Performance
|
Impedance chart range |
5 files can be adjusted |
|
Detection speed |
1～500m/min |
|
Frequency range |
100Hz-10MHz |
| Gain |
0～99dB，side size 0.1dB |
|
Advanced filtering |
Yes |
|
High pass |
0.1Hz～650Hz |
|
Low pass |
1Hz～10000Hz |
|
Phase rotation |
0-360° side size 1° |
|
Sampling rate |
1～200000SPS adjustable |
| Probe driving |
1%~100% adjustable |
| Synchronized alarm output controlled by internal and external clock |
| High Precision End and End Signal Excision Function |
| High Precision Real-time and Delayed Alarm Output |
| Fast Digital/Analog Electronic Balance |
| Delayed Hidden Removal Function with Memory Trajectory |
| Real-time impedance plane display |
| The instrument can match any probe |
| Remote Automatic Help System |
| Man-machine interface in Chinese and English |
|
Non-equal Amplitude Phase/Amplitude Alarm Domain |
| Computer Full Digital Parameter Adjustment |
